Tekin Gen4 Spec-R2 PRO Sensored Brushless Motor (17.5T)
TEKTT2690P
17.5 Gen4 Spec-R2 Pro BL Sensored Motor Tekin's SPEC-R2 brings next-level performance to SPEC racing classes. Improving on the original SPEC-R design, they revamped and refined the stator, rotor and materials used to increase both speed and torque while providing minimal fade during the late stages of the race. The SPEC-R2 is a hand-crafted, high-performance racing motor that is ready to hit the track right out of the box.
Includes: TT2782 12.5mm SILVER rotor. Setup critical, SILVER rotors are a special extra strong material and can be damaged by excessive heat from over-gearing and over-timing. Features: 60 Degrees Adjustable Timing Advance SPEC Racing Specific Design CNC Machined 6061-T6 Billet Aluminum Heat Sink Can Neodymium Sintered Magnet Precision Engineered for Maximum Energy Conversion High Purity Copper Windings Maximize Conductivity Sensored System Ready Anodized Endbell Plates Maximize Corrosion and Wear Resistance High RPM Precision Bearings Oversized Front Bearing Legal in Major Governing Race Bodies ROAR Approved Specifications: Motor Turns: 17.5T Input Voltage: 1S-3S LiPo/LiHV / 4.2V-13.05V Design: 2-pole 3-slot Weight: 5.25oz / 150g Shaft Size: 3.18mm / 1/8in Motor Length: 50.25mm / 1.987in Motor Diameter: 35.85mm / 1.40in Bearing Dimensions: Front 4 x 13 x 5mm / Rear 1/8 x 3/8 x 5/32in Rotor Size: TT2782 12.5mm Silver Max Operating Temperature: 180F / 82C Max RPM: 100,000 Mounting Pattern: M3 @ 25.4mm / M3 @ 1.0in Rebuildable: YES
